Chapter 3 Gas-Flow Controller
GC-2014 Service Manual
42
3.1.3 APC (Optional)
Different APCs are used for each detector.
3ch APC: FID FTD
2ch APC: FPD
1ch APC: ECD
3.1.3.1 3ch APC
APC_FID (Assembly Configuration Chart)
S221-73340-44
APC-2014+, FID
S221-48813-91
VALVE ASSY
S221-42511-92
RESISTANCE TUBE ASSY, H2, FID2010
PIPING ASSY, APC, INLET
FLOW BOARD ASSY, APC2
PCB ASSY, APC PCB APC ASSY, 3CH
PIPING ASSY, APC
APC_FTD (Assembly Configuration Chart)
S221-73340-45
APC-2014+, FID
S221-48813-91
VALVE ASSY
S221-18713-95
FTD-9 RESISTANCE TUBE ASSY, H2
S221-18713-96
FTD-9 RESISTANCE TUBE ASSY, AIR
PIPING ASSY, APC, INLET
FLOW BOARD ASSY, APC2
PCB ASSY, APC PCB APC ASSY, 3CH
PIPING ASSY, APC
