Chapter 6 Maintenance Parts List
GC-2014 Service Manual
65
Chapter 6 Maintenance Parts List
The main maintenance parts for the GC-2014 (Preparation Model for RoHS) are as follows.
Note: Compatibility (: Parts for the Preparation Model for RoHS can be used with
conventional models;

: An adapter is provided; : Incompatible)
6.1 Consumables
(Parts that require replacement after a period of use; parts that the user can replace)
GC-2014 Main Unit
P/N Description Previous P/N Compatibility Remarks
S201-35584 RUBBER SEPTUM, INJ. PORT

Pack of 20
S221-48398-91 HIGH-TEMPERATURE SEPTUM

Pack of 20
S036-11203-84 O-RING, 4D, P5

For INJ (pack of 5)
S221-48335-01 GLASS INSERT, SPLITLESS/WBI

S221-41444 GLASS INSERT, SPL17

S221-48600 SILICA WOOL, 2 G

Rendered inert
S221-32126-05 GRAPHITE FERRULE, G-0.5

Pack of 10
S221-32126-08 GRAPHITE FERRULE, G-0.8

Pack of 10
S221-34121-94 MS FILTER

Carrier gas line
S221-42559-92 PIPE TRAP

For SPLIT, PURGE lines

FID-2014 Single
P/N Description Previous P/N Compatibility Remarks
S221-70162-95
NOZZLE ASSY, GENERAL USE,
PACKED

S221-70162-92 NOZZLE ASSY, CAPILLARY, 0.5

S221-41847-93 FID IGNITER FILAMENT ASSY


FPD-2014
P/N Description Previous P/N Compatibility Remarks
S221-46310-01 S FILTER, FOR FPD (GC-2010)

S221-46310-02 P FILTER, FOR FPD (GC-2010)

S221-46310-03 Sn FILTER, FOR FPD (GC-2010)

S221-73430-93 IGNITER ASSY, FPD

S221-70735-91
SUS NOZZLE ASSY, FPD-2014 (FOR
CAPILLARY)

S221-70348-91
SILICA NOZZLE ASSY, FPD-2014 (FOR
PACKED)

S221-46552 SILICA TUBE, LARGE FPD

S221-70562 FPD PACKING

S036-11018 O-RING, 4C P18

Photomultiplier aperture
FTD-2014 Capillary
P/N Description Previous P/N Compatibility Remarks
S221-34121-94 MS FILTER

Aging complete
S221-48258-91 NOZZLE ASSY, FID

S221-71513-91 FTD COLLECTOR (GC-2010) S221-45586-91

(Not the same part)
S221-49079-91 COLLECTOR REGENERATION KIT


