Shimadzu GC-2014 Service Manual

Chapter 2 Configuration of GC-2014
GC-2014 Service Manual
13
2.1.6 GC-2014ATF
S221-75026-41
GC-2014ATF, 100 V
115 V: S221-75026-42
230 V: S221-75026-44
S221-75075-41
DULA AFC ASSY
S221-70090-91
FID-2014 CELL ASSY, P
S221-70040-41
FID-2014 CONTROLLER, DUAL
S221-75086-41
DET HEATER ASSY, FT, 100 V
115 V: S221-75086-42
230 V: S221-75086-44
S221-75049-41
FLOW CONTROLLER, H2-AIR, FID
S221-75063-41
ACCESSORY, GC-2014
S221-70041-41
TCD-2014 CONTROLLER
S221-70043-91
TCD POWER SUPPLY ASSY
S221-11386-94
TCD ACCESSORY SET
(8)
(18)
(4)
(15)
(16)
(17)
TCD-2014 CELL ASSY, 100 V
(19) (1)
(2)
(3)
(5)
(6)
GC-2014 ASSY, 100 V
PACKED DUAL INJ, 100 V
(14)

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
