Shimadzu GC-2014 Service Manual

Chapter 2 Configuration of GC-2014
GC-2014 Service Manual
11
2.1.3 GC-2014AFsc
S221-75020-41
GC-2014AFSC,100
115 V: S221-75020-42
230 V: S221-75020-44
S221-75049-41
FLOW CONTROLLER, H2-AIR, FID
S221-75049-44
FLOW CONTROLLER, AUX
S221-75064-41
ACCESSORY, SPL-2014, SINGLE
(8)
(11)
(12)
(10)
FID-2014,100-120 V
(1) GC-2014 ASSY, 100 V
(9) SPL-2014 ASSY, 100
2.1.4 GC-2014AFSPL
S221-75028-41
S221-75025-41
GC-2014AFSPL, 100
GC-2014AF, 100 V
115 V: S221-75028-42
115 V: S221-75025-42
230 V: S221-75028-44
230 V: S221-75025-44
221-70952-91
DETECTOR ADAPTER ASSY
(13)
SPL-2014 ASSY, 100
(9)
(20)

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
