Shimadzu GC-2014 Service Manual

Table of Contents
GC-2014 Service Manual
1
Table of Contents
Product Warranty......................................................................................................... II
Notice........................................................................................................................... II
Introduction ................................................................................................................. III
Maintenance Parts Availability.................................................................................... III
Listing of Part Numbers .............................................................................................. III
Conventions Used for Precautionary Information.......................................................IV
Chapter 1 Installation............................................................5
1.1 Installation Space................................................................................ 5
1.1.1 Rear Space........................................................................................................ 5
1.1.2 Side Space ........................................................................................................ 5
1.2 Installation Environment...................................................................... 5
1.2.1 Ambient Temperature and Humidity.................................................................. 5
1.2.2 Installation Surface............................................................................................ 6
1.2.3 Corrosive Gas and Dust.................................................................................... 6
1.2.4 Influence of Electromagnetic Waves and Power-Supply Noise ........................ 6
1.2.5 Other Precautionary Items ................................................................................ 6
1.3 Power Supply...................................................................................... 7
1.3.1 Power-Supply Voltage....................................................................................... 7
1.3.2 Power-Supply Capacity..................................................................................... 7
1.4 Gas ..................................................................................................... 8
1.4.1 Purity ................................................................................................................. 8
1.4.2 Supply Pressure ................................................................................................ 8
1.5 Work Related Precautions .................................................................. 8
Chapter 2 Configuration of GC-2014....................................9
2.1 Configuration Diagrams for GC-2014 Series ...................................... 9
2.1.1 GC-2014A.......................................................................................................... 9
2.1.2 GC-2014AF ..................................................................................................... 10
2.1.3 GC-2014AFsc...................................................................................................11
2.1.4 GC-2014AFSPL................................................................................................11
2.1.5 GC-2014AT...................................................................................................... 12
2.1.6 GC-2014ATF ................................................................................................... 13
2.1.7 GC-2014ATFSPL............................................................................................. 14
2.2 Structure of GC-2014........................................................................ 20
2.2.1 External Appearance ....................................................................................... 20
2.2.2 Structure Diagram 1 ........................................................................................ 21
2.2.3 Structure Diagram 2 ........................................................................................ 22
2.2.4 Structure Diagram 3 ........................................................................................ 23
2.2.5 PT Sensor and Thermocouple ........................................................................ 23
2.2.6 Heater and PT Sensor/Thermocouple............................................................. 24
2.2.7 Fan Motor ........................................................................................................ 24

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
