2-5
Hardware installation GettinG started
13. Raise the tray release to lock the HDD assembly. An audible click sounds when the tray is
locked.
Tray release
Locking the HDD Assembly
14. Close the bay cover.
2 1
2
1
Closing the HDD Bay Cover
15. To install a second hard disk drive, repeat the previous instructions.
Your system is now ready to connect your local network. See Connecting the Ethernet Port.
