Hardware installation GettinG started
10. Make sure the tray release is open before inserting the HDD assembly.
11. Align the HDD assembly (This side up label facing up) in the bay, see following gure.
12. Slide the HDD assembly into place until it is ush in the bay.
This side up
Tray release
Bottom side of tray
Installing the HDD Tray Assembly
WARNING:
HDD tray must be ush with the bay, see following illustration.
Correct
position
Incorrect
position
HDD Installation Position
