Sender
P
osition of LEDs: see "Sender displays", page 21.
Table 42: Indications on the sender when switching on
LEDs Meaning
STATE Field
Ö Y
ellow, flashes once
Beam coding, code 1 is c
onfig‐
ured.
Ö Y
ellow, flashes twice
Beam coding, code 2 is c
onfig‐
ured.
O R
ed ÖÖ Yellow/green
Reset of the configuration to
f
actory settings is activated,
see "Factory settings", page 93.
O R
ed Ö Green
Device is in configuration
mode
, see "Configuration
mode", page 95.
o LED of
f. Ö LED flashes. O LED illuminates. Empty cells mean that the LED lights up, flashes, or is off.
Receiver
P
osition of LEDs: see "Receiver displays", page 22.
Table 43: Indications on the receiver when switching on
LEDs End cap with
int
egrated
LED
Meaning
OSSD Field Diagnostic LEDs
1 2 3 4 5 6 7 8
Ö Y
el‐
low,
flashes
once
O
White
(3 s)
Ö Yellow,
flashes once
Beam coding,
code 1 is c
onfig‐
ured.
Ö Y
el‐
low,
flashes
twice
O
White
(3 s)
Ö Yellow,
flashes twice
Beam coding,
code 2 is c
onfig‐
ured.
O
W
hite
(3 s)
External device
monit
oring (EDM) is
configured.
O
W
hite
(3 s)
Cascade with 1
gue
st or 2 guest
devices is config‐
ured.
O
W
hite
(3 s)
Restart interlock is
conf
igured.
O
W
hite
(3 s)
Muting or partial
blank
ing is config‐
ured.
OR
Smart Box Detec‐
tion is configured.
O
W
hite
(3 s)
Reduced resolu‐
t
ion is configured.
TROUBLESHOOTING 11
8021645/1EB0/2022-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4
