SICK FX0-GMOD User Manual

8 Operation
8.1 Status messages on the FX3-CPUx main module
For information on the positions of the LEDs on the FX3-CPU0 main module, see
f
igure 27, page 53.
For information on the positions of the LEDs on the FX3-CPU1 and FX3-CPU2 main
modules, see figure 29, page 54.
For information on the positions of the LEDs on the FX3-CPU3 main module, see
figure 30, page 55.
MS LED (all main modules)
T
able 80: MS LED
MS LED Meaning Notes
o
Supply voltage out of range Switch on the voltage supply of the Flexi Soft sys‐
tem and check at the A1 and A2 terminals of the
main module.
Ö R
ed/
green (1Hz)
Self-test in progress or sys‐
t
em initializing.
Please wait ...
Ö Gr
een
(1Hz)
System in Stop The application can be started from within the
conf
iguration software.
Ö Gr
een
(2Hz)
Identify (e.g., for Flexi Link) –
O Gr
een
System in Run –
Ö R
ed
(1Hz)
Invalid configuration Check module type and module version of main
module and e
xpansion modules on which the MS
LED Ö is flashing red/green.
Modify the configuration if necessary.
Use the configuration software diagnostic func‐
tion.
Ö R
ed
(2Hz)
Serious error in the system,
pr
esumably in this module.
The application was stopped.
All outputs are switched off.
Switch thepower supply off and then on again.
If the problem still has not been remedied after
multiple repetitions, replace this module.
Use the configuration software diagnostic func‐
tion.
O R
ed
Serious error in the system,
pr
esumably in a different
module. The application was
stopped. All outputs are
switched off.
Switch thepower supply off and then on again.
If the problem still has not been remedied after
multiple repetitions, replace the module showing
Ö red (2Hz). If applicable, also use the diag‐
nostic function in the configuration software to
isolate the affected module.
CV LED (all main modules)
T
able 81: CV LED
CV LED Meaning Note
o
Configuration in progress. –
Ö Y
ellow
(2Hz)
Saving configuration data in
t
he system plug (non-volatile
memory)
Do not disconnect from power supply until save
process has been completed.
Ö Y
ellow
(1Hz)
Unverified configuration Verify the configuration with the configuration
sof
tware.
O Y
ellow
Verified configuration –
8 OPERATION
106
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice
