Table 94: Displays of the MS LED on the FX3-MOCx motion control module
MS LED Meaning Notes
o
Supply voltage out of range Switch on the voltage supply of the Flexi Soft sys‐
t
em and check at the A1 and A2 terminals of the
main module.
Ö R
ed/
green (1Hz)
Remediable external error Check the encoder signals.
Use t
he configuration software diagnostic func‐
tion.
Ö Gr
een
(1Hz)
System in Stop The application can be started from within the
conf
iguration software.
O Gr
een
System in Run
Ö R
ed
(1Hz)
Invalid configuration
Ö R
ed
(2Hz)
Serious error in the system,
pr
esumably in this module.
The application was stopped.
All outputs are switched off.
Switch thepower supply off and then on again.
If the problem still has not been remedied after
multiple repetitions, replace this module.
Use the configuration software diagnostic func‐
tion.
O R
ed
Serious error in the system,
pr
esumably in a different
module. The application was
stopped. All outputs are
switched off.
Switch thepower supply off and then on again.
If the problem still has not been remedied after
multiple repetitions, replace the module showing
Ö red (2Hz). If applicable, also use the diag‐
nostic function in the configuration software to
isolate the affected module.
8.8 Status messages of the UE410-2RO and UE410-4RO relay modules
For information on the positions of the LEDs on the UE410-2RO and UE410-4RO relay
modules, see figure 44, page 75 and see figure 45, page 75.
Table 95: Statuses indicated by the LEDs on the UE410-2RO and UE410-4RO relay modules
LED display Meaning
PWR (green) Supply voltage via safety bus on.
K1/2 (green) Relay K1/K2 – safety contacts closed
K3/4 (green) Relay K1/K2 – safety contacts closed (on the UE410-4RO only)
OPERATION 8
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
113
Subject to change without notice
