12.3.9 EBX1, EBX3 and EBX4 encoder/motor feedback connection units
General data
T
able 175: General data EBX1, EBX3 and EBX4
EBX1, EBX3 and EBX4
Protection class (IEC61140) III
Immunity to interference EN 61000-6-2
Emitted interference EN 61000-6-4
Wire cross-section Single-wire or fine-stranded wire: 0.2 … 1.5mm²
St
randed wire with ferrule:
a) With plastic ferrule max. 0.75mm²
b) Without plastic ferrule max. 1.5mm²
AWG to UL/CUL: 24 … 16
Mechanical data
T
able 176: Mechanical data EBX1, EBX3 and EBX4
EBX1, EBX3 and EBX4
Dimensions (W × H × D) 45mm × 142.3mm × 73.1mm
Weight EBX1: 119g
EBX3: 170g
EBX4: 163g
Ambient data
Table 177: Ambient data EBX1, EBX3 and EBX4
EBX1, EBX3 and EBX4
Enclosure rating (IEC60529) IP20
Ambient operating temperature
(UL/C
SA: surrounding air tempera‐
ture)
-25 ... +55°C
Storage temperature -25 ... +70°C
Air humidity ≤95%, non-condensing
Operating altitude Max. 2,000m above sea level (80kPa)
Vibration resistance 5–150Hz/1G (EN60068-2-6)
10–500Hz/3G
r
ms
(EN60068-2-64)
Shock resistance, continuous shock 15g, 11ms (EN 60068-2-27)
Shock resistance, single shock 30g, 11ms (EN 60068-2-27)
Electrical data
T
able 178: EBX1: Voltage supply for encoder ENC1_24V and ENC2_24V (from FX3-MOCx)
Minimum Typical Maximum
Supply voltage 24VDC (16.8 … 24 … 30VDC)
Supply voltage for UL/CSA applica‐
t
ions
+24VDC
Type of supply voltage PELV or SELV
The supply current for the encoder/motor feedback con‐
nection unit must be externally limited to a maximum
of 1 A – either by connecting it to the voltage supply at
the encoder connection of the FX3-MOCx, by the power
supply unit used or by a fuse.
Encoder voltage supply (ENC1_24V, ENC2_24V, ENC_0V)
TECHNICAL DATA 12
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
165
Subject to change without notice
