SICK FX0-GMOD - IO Module XTDS

XTDI
Output current Max. 120mA at each of the two test pulse generators
(
X1/X3/X5/X7 or X2/X4/X6/X8).
This makes max. 8 testable sensor cascades per mod‐
ule possible with max. 30mA each.
The total current of the FlexiSoft systems for all outputs
(X1 … X8 and XY1 … XY2) must not exceed 1.28A.
This corresponds, for example, to a maximum of 32 test‐
able sensor cascades each with 30mA plus 64 tactile
sensors on the inputs of expansion modules each with
5mA.
Test pulse rate (test period) 40 … 1,000ms, configurable
Test pulse width (test gap) 1 … 100ms, configurable
Load capacity 1µF for a test gap ≥4ms
0.5µF f
or a test gap of 1ms
Conductor resistance <100Ω
Mechanical data
T
able 139: Mechanical data XTDI
XTDI
Dimensions (W × H × D) 22.5 × 96.5 × 120.6mm
Weight 139g (±5%)
Ambient data
T
able 140: Ambient data XTDI
XTDI
Enclosure rating (IEC60529) IP20
Ambient operating temperature
(UL/C
SA: surrounding air tempera‐
ture)
-25 ... +55°C
Storage temperature -25 ... +70°C
Air humidity ≤95%, non-condensing
Operating altitude Max. 2,000m above sea level (80kPa)
Vibration resistance 5–150Hz/1G (EN60068-2-6)
10–500Hz/3G
r
ms
(EN60068-2-64)
Shock resistance, continuous shock 15g, 11ms (EN 60068-2-27)
Shock resistance, single shock 30g, 11ms (EN 60068-2-27)
12.3.4 I/O module XTDS
Safety-related parameters
The data apply to an ambient temperature of +40°C.
The safety-related parameters do not apply to outputs XY1, XY2 and Y3-Y6.
Table 141: Safety-related parameters XTDS
XTDS
Safety integrity level (IEC61508)
S
afety integrity level (IEC62061)
SIL 3
Category(ISO13849) Category 4
Performance level (ISO13849) PLe
TECHNICAL DATA 12
