SICK FX0-GMOD User Manual

XTDS
PFH
D
0.4 × 10
–9
PFD
a
vg
3×10
–5
T
M
(mis
sion time, ISO13849) 20 years
General data
T
able 142: General data XTDS
XTDS
Protection class (IEC61140) III
Immunity to interference EN 61000-6-2
Emitted interference EN 61000-6-4
Connection type Dual level spring terminals
Wire cross-section Single-wire or fine-stranded wire: 0.2 … 1.5mm²
Stranded wire with ferrule:
a) With plastic ferrule max. 0.75mm²
b) Without plastic ferrule max. 1.5mm²
AWG to UL/CUL: 24 … 16
Data interface Internal bus (FLEXBUS+)
Power consumption Max. 1.5W
Power loss
Interfaces
T
able 143: Interfaces XTDS
XTDS
Data interface Internal bus (FLEXBUS+)
Electrical data
T
able 144: Power supply unit (A1, A2) for XTDS
XTDS
Supply voltage 24VDC (16.8 … 24 … 30VDC)
Supply voltage for UL/CSA applica‐
t
ions
+24V DC
Type of supply voltage PELV or SELV
T
he supply current for the module must be limited exter‐
nally to max. 4A – either by the power supply unit used,
or by means of a fuse.
Short-circuit protection 4A gG (with trigger characteristics B or C)
Power consumption Max. 60W (30V × 2A), determined by the load on
out
puts Y3 to Y6
Power-up delay Max. 18s
Table 145: Safety inputs (I) XTDS
XTDS
Number of inputs 8
Input voltage High 13 ... 30V DC
1)
Input voltage Low -5 ... +5V DC
Input current High 2.4 ... 3.8mA
Input current Low -2.5 ... +2.1mA
12 TECHNICAL DATA
148
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice
