Table 202: Connecting cable for directly connecting two encoders
Part Type code Part number
•
S
hielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
straight
•
Flying leads
2m – 2067893
•
S
hielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
Flying leads
1.1m – 2098351
2m – 2077263
Pin assignment, see
table 41, page 70
Table 203: Y-connecting cable for directly connecting two encoders
Part Type code Part number
•
S
hielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
2× M12, female con‐
nector, 8-pin, straight
0.21m/0.21m
/0.41m
– 2094381
0.16m/0.14m
/0.14m
– 2116199
0.21m/2.74m
/2.74m
– 2100634
1.9m/0.49m/
0.27m
– 2117540
2.7m/0.69m/
0.19m
– 2117541
•
S
hielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
2× flying leads
0.21m/1.5m/
1.5m
– 2121173
Pin assignment, see
table 42, page 71
14.3 Accessories for the diode module
Table 204: Diode module DM8-A4K
Part Type code Part number
Diode module for connecting several short-cir‐
c
uit-forming safety pressure mats
DM8-A4K 6026142
14.4 Accessories for muting
Table 205: Muting lamp and cable
Part Type code Part number
Muting lamp with mounting kit – 2020743
LED muting lamp with 2m cable – 2019909
LED muting lamp with 10m cable – 2019910
14 ACCESSORIES
184
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice
