Minimum Typical Maximum
Output current
1)
– – 75mA
Load capacity – – 200nF
1)
The total output current is limited. Maximum sum current of all relay modules at Y14 or Y24is 80mA.
Mechanical data
T
able 186: Mechanical data UE410-2RO/UE410-4RO
UE410-2RO/UE410-4RO
Dimensions (W × H × D) 22.5mm × 96.5mm × 120.8mm
Weight UE410-2RO: 160g (±5%)
UE410-4R
O: 186g (±5%)
Ambient data
T
able 187: Ambient data UE410-2RO/UE410-4RO
UE410-2RO/UE410-4RO
Enclosure rating (IEC60529) IP20
Ambient operating temperature
(UL/C
SA: surrounding air tempera‐
ture)
-25°C ... +55°C
Storage temperature -25°C ... +70°C
Air humidity ≤95%, non-condensing
Operating altitude Max. 2,000m above sea level (80kPa)
Vibration resistance 5-150Hz/1G (EN 60068-2-6)
10-500Hz/3G
r
ms
(EN 60068-2-64)
Shock resistance, continuous shock 15g, 11ms (EN 60068-2-27)
Shock resistance, single shock 30g, 11ms (EN 60068-2-27)
12.3.11 Diode module DM8-A4K
General data
T
able 188: General data diode module DM8-A4K
Diode module DM8-A4K
Stripping length 7 mm
Wire cross-section 0.2 … 2.5 mm²
Screw connection AWG 22–14
Protection class (IEC61140) III
Contamination rating 2
Electrical data
T
able 189: Input data for diode module DM8-A4K
Diode module DM8-A4K
Input voltage (max.) 25 V AC/60 V DC
Reverse voltage 1,000 V
Reverse current 5 µA
Forward voltage 0.8 V
Input current per channel (1/2) 400 mA
12 TECHNICAL DATA
170
