Response time Depending on the logic configuration, for details see:
see
table 97, page 132
1)
In the event of an error (GND line open circuit) and with a load resistance of at least 2.5kΩ, no more than
t
he specified leakage current flows on the output. For lower load resistances, the leakage current may be
greater; however, the output voltage will be <5V in this case. A downstream device, for example a relay
or a FPLC (fail-safe programmable logic controller) must detect this state as Low.
2)
Example of resulting maximum coil induction: 2,960mH @ 0.5A.
Mechanical data
T
able 148: Mechanical data XTDS
XTDS
Dimensions (W × H × D) 22.5mm × 96.5mm × 120.6mm
Weight 139g (±5%)
Ambient data
T
able 149: Ambient data XTDS
XTDS
Enclosure rating (IEC60529) IP20
Ambient operating temperature
(UL/C
SA: surrounding air tempera‐
ture)
-25 ... +55°C
Storage temperature -25 ... +70°C
Air humidity ≤95%, non-condensing
Operating altitude Max. 2,000m above sea level (80kPa)
Vibration resistance 5–150Hz/1G (EN60068-2-6)
10–500Hz/3G
r
ms
(EN60068-2-64)
Shock resistance, continuous shock 15g, 11ms (EN 60068-2-27)
Shock resistance, single shock 30g, 11ms (EN 60068-2-27)
Immunity to interference EN 61000-6-2
12.3.5 I/O module STIO
General data
T
able 150: General data STIO
STIO
Protection class (IEC61140) III
Immunity to interference EN 61000-6-2
Emitted interference EN 61000-6-4
Connection type Dual level spring terminals
Wire cross-section Single-wire or stranded: 0.2 … 1.5mm²
St
randed wire with ferrule:
a) With plastic ferrule max. 0.75mm²
b) Without plastic ferrule max. 1.5mm²
AWG to UL/CUL: 24 … 16
Power consumption Max. 1.5W
Power loss
12 TECHNICAL DATA
150
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice
