Connecting cables
T
able 199: Connecting cable for FX3-MOCx and FX3-EBXx
Part Type code Part number
•
S
hielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
straight
•
1× D-sub, male connec‐
tor, 15-pin, straight
2m – 2067798
10m – 2067799
•
Shielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
1× D-sub, male connec‐
tor, 15-pin, straight
0.5m – 2111541
2m – 2077261
10m – 2077262
Pin assignment, see
table 39, page 69
Table 200: Connecting cable for FX3-EBX3 and FX3-EBX4
Part Type code Part number
•
S
hielded, twisted pair
•
1× D-sub, male connec‐
tor, 9-pin, straight
•
1× D-sub, male connec‐
tor, 15-pin, straight
0.3m – 2078260
2m – 2067800
10m – 2067801
Pin assignment, see table 40, page 69
Table 201: Connecting cable for direct encoder connection
Part Type code Part number
Sine/Cosine encoder, e.g.,
DF
S60SPro
•
Shielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
1× M12, female con‐
nector, 8-pin, straight
1m – 2094403
3m – 2094426
5m – 2094427
10m – 2094428
SSI encoder
•
Shielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
1× M12, female con‐
nector, 8-pin, straight
1m – 2094402
3m – 2094431
5m – 2094432
10m – 2094433
SSI + Sin/Cos encoder,
e.g., AFS/AFM60Spro
•
Shielded, twisted pair
•
1× Micro D-sub,
male connector, 15-pin,
angled
•
1× M12, female con‐
nector, 12-pin, straight
1m – 2094372
3m – 2094434
5m – 2094435
10m – 2094436
Pin assignment
•
see
table 43, page 72
•
see table 44, page 73
•
see table 45, page 73
ACCESSORIES 14
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
183
Subject to change without notice
