SICK FX0-GMOD User Manual

Necessary module with firmware
fr
om version
Available from
Flexi Soft
Designer
Available from
Safety Designer
Automatic circuit diagrams Unrestricted V1.3.0 V1.6.x
Central tag name editor Unrestricted V1.3.0 V1.6.x
Documentation for function blocks of main mod‐
ule
s in logic editor
Unrestricted V1.3.0 N. a.
1)
Matrix of input and output connections Unrestricted V1.3.0 V1.6.x
Invertible inputs for the function blocks AND, OR,
R
S Flip-Flop and Routing n:n
FX3-CPUx V2.00.0 (Step 2.xx) V1.3.0 V1.6.x
Function block for ramp-down detection FX3-CPUx V1.11.0 (Step 1.xx) V1.3.0 V1.6.x
Function blocks for configurable switch-on delay
and configurable switch-off delay
FX3-CPUx V2.00.0 (Step 2.xx) V1.3.0 V1.6.x
Speed to Bool function block FX3-MOC0 V1.10.0 V1.7.0 V1.6.x
Motion Status to Bool function block FX3-MOC0 V1.10.0 V1.7.0 V1.6.x
Verification possible even without identical hard‐
w
are
FX3-CPUx V2.00.0 (Step 2.xx) V1.3.0 V1.6.x
Status input data and status output data in logic FX3-CPUx V2.00.0 (Step 2.xx)
and FX3-
XTIO, FX3-XTDI, or FX3-
XTDS, each V2.00.0 (Step 2.xx)
V1.3.0 V1.6.x
Easy applications for FX3-MOC0 FX3-MOC0 V1.10.0 V1.7.1 N. a.
Special functions
Two S3000 safety laser scanners on one EFI
int
erface
FX3-CPU1 V1.00.0 V1.2.2 N. a.
Flexi Link FX3-CPU1 V2.00.0 (Step 2.xx) V1.3.0 N. a.
Flexi Loop FX3-CPUx V3.00.0 (Step 3.xx)
and FX3-
XTIO, FX3-XTDI, or FX3-
XTDS, each V3.00.0 (Step 3.xx)
V1.6.0 V1.8.0
Flexi Line FX3-CPU3 V3.00.0 (Step 3.xx) V1.6.0 N. a.
Automatic configuration of connected EFI-ena‐
bled s
afety sensors (automatic configuration
recovery)
FX3-CPU2 V3.00.0 (Step 3.xx) V1.5.0
(FX3-CPU2)
V1.6.0
(FX3-CPU3)
N. a.
Deactivation of test signals Q1 to Q4 on the FX3-
X
TIO possible
FX3-XTIO V2.00.0 (Step 2.xx) V1.3.0 V1.6.x
Fast shut-off with bypass at FX3-XTIO FX3-CPUx and FX3-XTIO, each
V2.00.0
(Step 2.xx)
V1.3.0 V1.6.x
Multiple safety mats at FX3-XTIO/FX3-XTDI FX3-XTIO or FX3-XTDI, each V1.13.0 V1.3.0 V1.6.x
Data recorder FX3-CPUx V2.00.0 (Step 2.xx) V1.5.0 V1.6.x
Extended cross-circuit detection time for the
s
witching of increased capacitive loads at FX3-
XTIO
FX3-XTIO V3.00.0 (Step 3.xx) V1.6.0 V1.6.x
Configurable filter time for in/out filters and
out/in filters at inputs I1 to I8 at FX3-XTIO/FX3-
XTDI/FX3-XTDS
FX3-XTIO, FX3-XTDI, or FX3-XTDS,
each V3.00.0 (Step 3.xx)
V1.6.0 V1.6.x
Optimization of logic execution time FX3-CPUx V4.00.0 (Step 4.xx) V1.7.1 V1.6.x
Automated download No limitation V1.9.1 n.a.
Checksums for logic pages and user-defined
f
unction blocks
No limitation V1.9.3 n.a.
Licensed SICK safety systems FX3-CPUx V4.00.0 (Step 4.xx) V1.9.4 n.a.
PRODUCT DESCRIPTION 3
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
