5.2.9.1 Pin assignment FX3-EBX1
C1 encoder connection
T
able 28: C1 encoder connection, FX3-EBX1
Terminal Designation Wiring
Sine/Cosine encoder A/B incremental encoder SSI encoder
2output
pair
s
(HTL24V,
HTL12V,
TTL)
2outputs
(HTL24V,
HTL12V,
TTL)
2output
pairs
(RS-422)
1 NC2 Not connected to the FX3-EBX1
1)
2 NC1 Not connected to the FX3-EBX1
1)
3 ENC1_24V 24V voltage supply for encoder
4 ENC1_0V GND connection for encoder
5 ENC1_C– – – – – B– Clock -
6 ENC1_C+ – – – – B+ Clock+
7 ENC1_B– Sin– Sin_Ref B– GND – –
8 ENC1_B+ Sin+ Sin B+ B – –
9 ENC1_A– Cos– Cos_Ref A– GND A– Data–
10 ENC1_A+ Cos+ Cos A+ A A+ Data+
1)
Used to forward a signal, e.g. for an external voltage supply.
ELECTRICAL INSTALLATION 5
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
63
Subject to change without notice
