Electrical values 0V ≤ V
out
2)
≤ V
S
(V
S
−1.5V) ≤V
out
≤V
S
at I
out
3)
≤50mA
1)
Supply voltage.
2)
Output voltage.
3)
Output current.
NOTE
Provide an arc-suppression switch at the digital output if inductive load is present.
►
Attach a freewheeling diode directly to the load for this purpose.
NOTE
Capacitive loads on the digital outputs have an effect on the switch-on and switch-off
behavior. A maximum capacitance of 100nF is the limit value.
Function assignment
NOTE
Allocate the functions for the digital outputs in the device using a configuration soft‐
ware, e.g., SOPASET.
Wiring digital outputs via connection module
Connection modules Digital outputs Reference
CDB650-204 RES/OUT 1
RES/OUT 2
RES/OUT 3
see "Wiring digital outputs of
the device in the CDB650-204",
page 69
CDM420-0006 Result 1
Result 2
see "Wiring digital outputs of
the device in the CDM420-0006",
page 78
ELECTRICAL INSTALLATION 6
8024830/1MBT/2024-05-22 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector61x
41
Subject to change without notice
