Configurable functions
M4000 Area 60
You can set the M4000 Area 60 multiple light beam safety device to two different
scanning ranges. The effective scanning range is dependent here upon the dimension of
the light path between sender and receiver and the number of additional front screens
used. You will find the necessary scanning ranges and the resulting setting in Tab. 10.
The following scanning ranges are available:
• low scanning range (0.5-6 m)
• high scanning range (5-19 m)
Device symbol M4000 Area (receiver), context menu Open device window, parameter
node General.
Number of additional front
screens
M4000 Area 60 with short
scanning range
M4000 Area 60 with long
scanning range
Without 0.5-6.0 m 5.0-19.0 m
1 0.5-5.5 m 5.0-17.4 m
2 0.5-5.0 m 5.0-15.9 m
M4000 Area 80
You can set the M4000 Area 80 multiple light beam safety device to two different
scanning ranges. The effective scanning range is dependent here upon the dimension of
the light path between sender and receiver and the number of additional front screens
used. You will find the necessary scanning ranges and the resulting setting in Tab. 11.
The following scanning ranges are available:
• low scanning range (0.5-20 m)
• high scanning range (15-70 m)
Device symbol M4000 Area (receiver), context menu Open device window, parameter
node General.
Number of additional front
screens
M4000 Area 80 with short
scanning range
M4000 Area 80 with long
scanning range
Without 0.5-20.0 m 15.0-70.0 m
1 0.5-18.4 m 15.0-64.4 m
2 0.5-16.9 m 15.0-59.2 m

Tab. 10: Scanning range of
the M4000 Area 60 as a
function of the number of
additional front screens

Tab. 11: Scanning range of
the M4000 Area 80 as a
function of the number of
additional front screens
