SICK MARSIC300 User Manual

Table 5: Passwords
Password for Password Change password
Device display access "Authorized
User"
1234 Changing the password: see "Instrument display",
page 60
SOPAS ET HIDE Cannot be changed
4.5 Using the menus
Example: Menu: Parameterization/I/O/Data/External Data/Analog inputs
Figure 47: Menu Analog inputs
Table 6: Menu fields legend
Entry field Significance
1
Save current entries.
2
Create group
b
Click "Mark" and then click the desired lines.
b
To cancel "Mark": Click "Mark" again and then click an empty line.
3
In editable menus: Call up the setting menu for lines.
b
Click desired line. Then click "Edit".
4
Copy selected lines
5
Insert copied lines before a selected line
6
Call up "Next function group"
(The bottom lines in the example depend on the menu)
4.6
Menu tree (SOPAS ET)
The menu tree shown here shows the menus for user level "Authorized User".
Menu Reference
Measuring screen chapter 5.1
Measuring screens
Diagnosis chapter 7
Control values chapter 7.1
Zero drift
Span gas drift
Internal adjustment drift
Reference energy
Intensity
Sensor values chapter 7.2
Temperatures
Pressures
Flow rate
Cell
O2 sensor
Emitter
Motors
4 CONFIGURATION SOFTWARE
42
T E C H N I C A L I N F O R M A T I O N | MARSIC300 8017585/YXD9/V3-1/2017-05 | SICK
Subject to change without notice
