SICK MARSIC300 User Manual

10.2 Design
Table 13: Design
Design
Design 1 x wall housing
Material, general Steel plate, aluminium cast
Dimensions see "Dimensional drawings", page 78
Installation Wall fitting
Weight Approx. 120 kg
Materials with media contact
•
Stainless steel 1.4571
•
PTFE
•
Aluminium (coated)
Degree of protection IP 54
10.3 Measuring parameters
Table 14: Sample gases
Variants Components
DeSO
x
SO
2
, CO
2
, H
2
O, optional O
2
DeNO
x
NO, NO
2
, H
2
O, optional O
2
Emission SO
2
, CO
2
, NO, NO
2
, CO, CH
4
, NH
3
, H
2
O, optional O
2
Table 15: Measured variables
Number of measured variables
Number of measured variables Max. 9
Table 16: Measuring method
Measuring method
Measuring method Hot extractive
Table 17: Spectral range
Spectral range
Spectral range 2000 ... 11000 nm
Table 18: Sample volume
Sample volume
Sample volume 200 ... 300 l/h
Table 19: Sample gas - measuring range
Component Measuring range
SO
2
0 ... 30 ppm; 0 ... 2000 ppm
CO
2
0 ... 25% by vol.
O
2
0 ... 21% by vol.
NO 0 ... 300 ppm; 0 ... 2000 ppm
NO
2
0 ... 200 ppm; 0 ... 500 ppm
CO 0 ... 200 ppm; 0 ... 2000 ppm
NH
3
0 ... 50 ppm; 0 ... 500 ppm
CH
4
0 ... 500 ppm; 0 ... 10000 ppm
TECHNICAL DATA 10
8017585/YXD9/V3-1/2017-05 | SICK T E C H N I C A L I N F O R M A T I O N | MARSIC300
79
Subject to change without notice
