SICK MARSIC300 User Manual

1 About this document
1.1 Function of this document
This document describes:
•
Installation
•
Initial start-up
•
Operation via SOPAS ET
NOTICE
This technical documentation is only valid in combination with the MARSIC300 Operat‐
ing Instructions.
1.2 Target group
This document is addressed to technicians (persons with technical understanding)
operating and maintaining the measuring system.
The technicians must have been trained on the device.
Requirements for the technician
•
The technician must be familiar with the exhaust gas technology on the ship (over‐
pressure, toxic and hot flue gases) and be able to avoid hazards when working on
gas ducts.
•
The technician must be familiar with handling compressed gas cylinders (test
gases).
•
The technician must be able to avoid hazards caused by noxious test gases.
•
Only allow an authorized electrician to work on the electrical system or electrical
subassemblies.
1.3 Further information
•
SFU Gas Sampling System Operating Instructions
•
Sample Gas Line Operating Instructions
•
System documentation
•
Short instructions for MARSIC300
•
Optional: MPR (Meeting Point Router) Operating Instructions
•
Optional: Instrument Air Conditioning Operating Instructions
•
Optional: External Measuring Point Switchover Operating Instructions
•
Optional: Pressure Test Tool Operating Instructions
•
Optional: Profibus/Profinet Converter Operating Instructions
•
Optional: HOTSAMPLER (measuring point extension) Operating Instructions
1.4 Symbols and document conventions
1.4.1 Warning symbols
Table 1: Warning symbols
Symbol Significance
Hazard (general)
Hazard by voltage
1 ABOUT THIS DOCUMENT
6
T E C H N I C A L I N F O R M A T I O N | MARSIC300 8017585/YXD9/V3-1/2017-05 | SICK
Subject to change without notice
