6 Parameterization
6.1 Measuring components
Global definitions
This menu displays the global device information (e.g.: number of filter wheels, number
of activated components).
Figure 55: Menu Parameterization/Measuring component/Global Definitions
1
Active measuring components. Checkmark: Active
2
Internal use: Error threshold of reference energy as from which a message is generated.
Definition of measuring components
This menu displays the setting for the respective measuring component.
This menu only serves as information.
Figure 56: Menu Parameterization/Measuring components/Definition of
components
6.2 Measuring screens
Up to 8 Measuring screens can be configured and displayed:
Figure 57: Menu Tree Parame‐
ters/Measuring Screens in
SOPAS ET
Select the desired Measuring screen
PARAMETERIZATION 6
