PT100 DIGITAL INPUTS DIGITAL OUTPUTS VALVE OUTPUTS
Figure 16: Connection diagram - digital connections
2.12 Air and gas connections on analyzer
WARNING
Hazard when pressure is too high
Hoses can burst when the pressure is too high.
b
Observe the maximum pressures of the gases provided by the operator: see "Sup‐
ply gases", page 87.
Figure 17: Overview - air and gas connections
1
Heated sample gas line for measuring point 1
2
Heated sample gas line for measuring point 2 (option)
2 INSTALLATION
20
T E C H N I C A L I N F O R M A T I O N | MARSIC300 8017585/YXD9/V3-1/2017-05 | SICK
Subject to change without notice
