External signals
Digital signals
Menu: Diagnosis/Signals/External signals/Digital signals
Figure 94: Menu Digital signals
This menu displays the current state of
the digital signals (DIi, DOi, limit val‐
ues)
Digital values:
. = off (0)
I = on (1)
Measuring signals
Menu: Diagnosis/Signals/Measuring signals
Figure 95: Menu Measuring signals
This menu displays the measuring sig‐
nals.
Let SICK Customer Service evaluate
these signals.
Internal signals
Menu: Diagnosis/Signals/Diagnosis internal
Figure 96: Menu Internal signals
This menu displays the signals.
Let SICK Customer Service evaluate
these signals.
