Trigger: Sequence control programs
Table 45: Error codes - Sequence control program
Code Triggered by sub‐
assembly
C Message Clearance
M001
...
M009
Internal heating F Alarm from "device" " device " = triggering subassembly
Clearance see above: S001 and S002
M010
...
M029
External heating F Alarm from "device" " device " = triggering subassembly
Clearance see above: S001 and S002
M034
...
M045
System X System xx disabled
by user
No action required
M046
...
M057
Measuring point
1
...
Measuring point
12
M Flow alarm (meas‐
uring)
Clearance see above: S004
Next measuring point activation after mes‐
sage acknowledged
Table 46: Further error codes
Code Triggered by sub‐
assembly
C Message Clearance
M058 System F Flow alarm (meas‐
uring)
Clearance see above: S004
Next measuring point activation after mes‐
sage acknowledged
M060 Program M Adjust zero not
started
No action necessary
M062 Leak tightness
check
X Test passed
M063 M Test failed Repeat test and observe messages dis‐
played;
Check seating of connections, disconnect
heating hose from cell and close sample
gas inlet off with dummy plug (from leak
tightness check set)
If leaky: Exchange pressure control module
and cell otherwise exchange gas sampling
system
M064 Pressure not
reached
M065 Air valve not closed
M066 Leakage > Limit
M067 X Deviation="xx" Serves as information
"xx" = pressure loss [hPa] during measuring
time.
Table 47: Further error codes
Code Triggered by sub‐
assembly
C Message Clearance
M069 Debug X Internal message No action necessary
M070 Light Source M Lifetime exceeded Replace emitter
M071 Filter Unit M Lifetime filter
exceeded
Replace gas sampling system filter
M072 Valve driver mod‐
ule
F Temperature >
Limit
Other temperature error pending? Then see
S001 above;
Otherwise replace valve block
M073 Power Supply X 115V Serves as information
No action necessary
ANNEX 11
8017585/YXD9/V3-1/2017-05 | SICK T E C H N I C A L I N F O R M A T I O N | MARSIC300
99
Subject to change without notice
