SICK MLG-2 WebChecker User Manual

Table 48: Functional configuration
Designation Description
F1 to F10 You can parameterize up to 10 functions.
Enabled Activate or deactivate function.
Color Select color for display of the function.
Type Select function:
•
Widt
h measurement: Calculate width between two selected
edges.
•
Center measurement: Calculate center position between two
selected edges.
Edge number Select first edge used for calculation.
Options: Edge 1 to edge 10
Edge number Select second edge used for calculation.
Opt
ions: Edge 1 to edge 10
“Width measurement” example
The c
alculation between edges E1 and E2 should be calculated.
1. Activate the checkbox for “F1” in the "Activated" column.
2. Select the “Width measurement” function in the “Type” column.
3. Select the "Position of edge 1” option in the “Edge number” column.
4. Select the "Position of edge 2” option in the “Edge number” column.
✓
The width between edges E1 and E2 is calculated. The result is displayed on the
“Start” and “Enhanced Sensing” pages.
The selected edges do not have to be adjacent. You can have the widths between all
detected edges calculated. For example, you can have the distance between two
objects calculated with the “Width measurement” function.
“Center measurement” example
The cent
er position between edges E1 and E2 should be calculated.
1. Activate the checkbox for “F2” in the "Activated" column.
2. Select the “Center measurement” function in the “Type” column.
3. Select the "Position of edge 1” option in the “Edge number” column.
4. Select the "Position of edge 2” option in the “Edge number” column.
✓
The center position between edges E1 and E2 is calculated. The result is displayed
on the “Start” and “Enhanced Sensing” pages.
The selected edges do not have to be adjacent. You can have the center positions
between all detected edges calculated. For example, you can have the center position
between two objects calculated with the “Center position” function.
11 CONFIGURATION WITH SOPAS
102
O P E R A T I N G I N S T R U C T I O N S | MLG-2 WebChecker 8025190/2020-01-13 | SICK
Subject to change without notice
