SICK MLG-2 WebChecker User Manual

Distance between sender and
rec
eiver
Optimal distance between
object and sender
Optimal distance between
object and sender
[mm] [%] [mm]
1900 67.1 1,274.9
2000 67.0 1,340.0
2100 67.0 1,407.0
2200 66.9 1,471.8
2300 66.8 1,536.4
2400 66.7 1,600.8
2500 66.6 1,667.5
15.3.3 accuracy
Additional information
•
see "P
lannin
g", page 25
0
0,1
0,2
0,3
0,4
0,5
0,6
0,7
0,8
0,9
–80 –60 –40 –20 0 +20 +40 +60 +80
Genauigkeit einer Bahnkante in mm (± 0,3 mm)
Objektposition relativ zur Optimalposition in mm
a: 200 mm
b: 400 mm
c: 600 mm
d: 1000 mm
e: 2500 mm
1,0
Sender-Empfänger-Abstand
e e
dd
cc
bb
aa
15 TECHNICAL DATA
118
O P E R A T I N G I N S T R U C T I O N S | MLG-2 WebChecker 8025190/2020-01-13 | SICK
Subject to change without notice
