The LED flashes evenly.
ôKõ
The LED flashes briefly.
o
The LED is off.
b
T
ak
e action ...
Instructions for taking action are indicated by an arrow. Carefully read and follow the
instructions for action.
CAUTION
War
ning!
A warning indicates a specific or potential hazard. This is intended to protect you
against accidents.
Read carefully and follow the warnings!
s r S
ender and receiver
In f
igures and connection diagrams, the symbol s indicates the sender and r indi‐
cates the receiver.
1.6 Abbreviations used
EDS Electronic data sheet
ESI
E
t
her‐
CAT
®
Slave Information = electronic data sheet in XML
GSDML General station description markup language
MLG-2 Measuring automation light grid of the 2nd generation
MSB Most significant bit
SDD SOPAS device description
PLC Programmable logic controller
1 ABOUT THIS DOCUMENT
8
O P E R A T I N G I N S T R U C T I O N S | MLG-2 WebChecker 8025190/2020-01-13 | SICK
Subject to change without notice
