SICK MLG-2 WebChecker User Manual

3 Product description
3.1 Type labels of the MLG-2 WebChecker
The senders and receivers of the MLG-2 each have a type label.
2
5
1
34
11104
7
6
5
9
3
2
1
Figure 1: Sender type label
1
Type code
2
Part number for the individual sender
3
Part number for the whole MLG-2
4
Sender symbol
5
Firmware version
6
Required voltage supply
7
Maximum output current
8
Serial number
9
Data Matrix code, contains the part numbers of the sender, the part number of the
MLG
-2, and the serial number
ß
Display for male connector M12 / 5-pin
à
Display for pin assignment
3
2
1
8
7
6
5
4
9
10
Figure 2: Receiver type label
1
Type code
2
Part number for the individual receiver
3
Part number for the entire MLG-2
4
Receiver symbol
5
Firmware version
6
Required voltage supply
7
Maximum output current
8
Serial number
9
Data Matrix code, contains the part numbers of the receiver, the part number of the
MLG
-2, and the serial number
ß
FBA - MAC address
PRODUCT DESCRIPTION 3
8025190/2020-01-13 | SICK O P E R A T I N G I N S T R U C T I O N S | MLG-2 WebChecker
11
Subject to change without notice
