Page #113 background imageLoading...
Page #113 background image
Error per sheet width and temperature
chan
ge
0.17 mm / (1 m * 10 K)
Select the read direction from the connection side if
there are large temperature fluctuations.
Analog output resolution
2
Depends on the MLG-2 variant.
Mea
surement field width x 0.0625 mm/mA
Measuring range 4 ... 20 mA at 12 bit resolution
Maximum number of detectable edges 10
Maximum object transmission
3
80%
Minimum transmission difference per
ed
g
e
20%
1
Conditions: Sheet edge in optimal object position, fluctuation in read direction < ± 100 mm, constant
ambient temperature
2
The resolution of the analog outputs can influence the accuracy. The longer the measurement field width,
the lar
ger the influence.
3
In materials with high transmission, the temperature difference between the operating temperature and
the t
emperature during teach-in must be less than ± 15 K.
Required distances
Table 62
: MLG-2 data sheet – required distances
Optimal object position see "Optimal object position", page 117
"Measurement field border - edge" mini‐
mum distance (distanc
e A)
T
ypic
al distance: 23 mm
Minimum distance under ideal conditions:
8 mm
1
“Edge - edge” minimum distance (dis‐
tanc
e B)
T
ypical distance: 25 mm
Minimal distance for ideal conditions: 10 mm
1
1
Ideal conditions: uniform material, optimal ambient conditions and optimal object position
15.2 MLG-2 WebChecker fieldbus module data sheet
Table 63: Fieldbus module data sheet – general data
Protection class III (EN 61140)
Enclosure rating IP 65 and IP 67 (EN 60529)
1)
Ambient operating temperature –30 … +55 °C
Storage temperature –40 … +70 °C
Vibration resistance 5 g, 10 … 55 Hz (EN 60068-2-6)
Shock resistance (EN 60068-2-27)
Single shoc
k
Continuous shock
15 g, 11 ms
10 g
, 16 ms
Electromagnetic compatibility According to EN 61000-6-2 Interference immunity
f
or indus
trial environments and EN 61000-6-4
Emission standard for industrial environments
MTTF
MT
BF
15 years
15 years
Firmware version see "Type labels of the MLG-2 WebChecker",
pag
e 11
Dimensions see "MLG-2 WebChecker dimensional drawing",
page 119
Weight 350 g
Materials
Housing
Zinc
, painted
1)
Do not use light grids outdoors without protection (condensation will form).
TECHNICAL DATA 15
8025190/2020-01-13 | SICK O P E R A T I N G I N S T R U C T I O N S | MLG-2 WebChecker
113
Subject to change without notice
