Table 58: MLG-2 data sheet - inputs
Input voltage 0 V … V
S
Logic level switching points
•
HIG
H
•
LOW
•
> 15 V
•
< 5 V
T
he pulse dur
ation must be greater than the
response time: see "Response time", page 114
Outputs
Table 59
: MLG-2 data sheet - outputs
Switching mode Push-pull
Logic level switching points
•
H
IG
H
•
LOW
•
V
S
– 3 V
•
< 3 V
Maximum output current per output ≤ 100 mA
Output load per output
•
C
apacit
ive
•
Inductive
•
100 nF
•
1 H
Load resistance for analog output 4 …
20 mA
< 600 W
Response time see "Response time", page 114
Ethernet interface
T
able 60
: MLG-2 data sheet - Ethernet interface
Data transmission rate 100 Mbit/s
Default IP address 192.168.200.100
Subnet mask 255.255.255.000
Protocol TCP/IP
Maximum length of cable According to IEE802.3 (typ. 100 m)
Technical measurement data
Table 61
: MLG-2 data sheet – technical measurement specifications
Light sender LED, infrared
Wavelength 850 nm
Ambient light immunity 100,000 lx
Beam separation 5 mm
Number of beams (Number of connection side module + number of
he
ad side module
s) x 30 (without empty modules)
Measurement field width 145 … 3,145 mm including empty modules
Limiting range 3.5 m
Operating range 2.5 m
Minimum scanning range 0.2 m
Initialization time after switch-on < 1 s
Response time see "Response time", page 114
Cycle time 32 µs per beam
Accuracy of a sheet width
1
± 0.3 mm
see "acc
uracy", page 118
Repeatability 6 µm (1 sigma, 0% object transmission)
15 TECHNICAL DATA
112
O P E R A T I N G I N S T R U C T I O N S | MLG-2 WebChecker 8025190/2020-01-13 | SICK
Subject to change without notice
