4.8 Functions: Calculation of width and center positions
You can parameterize up to 10 functions via SOPAS. The following functions are possi‐
ble
:
•
C
alculate width between 2 edges.
•
Calculate distance between 2 edges
The results of the functions are designated F1 to F10.
rs
5
1
4
13.5
A
A
62
ca. 1/3
ca. 2/3
10
1
3
2
Figure 24: Example: Measured edges, calculated width
1
Object
2
Sequence of attenuation
3
Edge position 1
4
Calculated width between edges 1 and 10
5
Edge position 10
You can select every measured edge for the functions. The edges do not have to be
ad
jac
ent.
Additional information
•
see "“Functional configuration” menu", page 101
4 P
LANNING
32
O P E R A T I N G I N S T R U C T I O N S | MLG-2 WebChecker 8025190/2020-01-13 | SICK
Subject to change without notice
