If, on the other hand, configuration is done without empty modules, but the number of
edg
es still exceeds 10, the first five edges on the connection side are assigned to
edges 1 ... 5, the last five edges on the head side are assigned to edges 6 ... 10 (see
figure 23, page 30).
Table 15: Edge measurement and edge designation, various cases with empty modules
Case Edge measurement and edge designation
There are 5 edges on each the connection side
and on the he
ad side.
•
Connection side: 5 edges
•
Head side: 5 edges
•
Total: 10 edge
All edges on the connection side and the head
side are measured.
There are fewer than 5 edges on the connec‐
tion side and on t
he head side.
•
Connection side: < 5 edges
•
Head side: < 5 edges
•
Total: < 10 edges
All edges on the connection side and the head
side are measured.
There are more than 5 edges on the connec‐
tion side or on t
he head side.
•
Connection side or head side: > 5 edges
•
Total: > 10 edges
The first 5 edges in read direction are read on
each the connection side and on the head
side. The remaining edges are not measured.
There are fewer than 5 edges on the connec‐
tion side
. There are more than 5 edges on the
head side.
•
Connection side: < 5 edges
•
Head side: > 5 edges
•
Total: > 10 edges
All edges on the connection side are mea‐
sured. On the head side, the edges in read
direction are measured until the total edge
number of 10 is reached.
There are fewer than 5 edges on the head
side, t
here are more than 5 edges on the con‐
nection side.
•
Connection side: > 5 edges
•
Head side: < 5 edges
•
Total: > 10 edges
All edges on the head side are measured. On
the connection side, the edges in read direc‐
tion are measured until the total edge number
of 10 is reached.
Table 16: Edge measurement and edge designation, various cases without empty modules
Case Edge measurement and edge designation
There are 10 edges in the measurement field
•
Total: 10 edge
All edges are measured and counted with edge
1… 10
There are fewer than 10 edges in the measure‐
ment fie
ld
•
Total: < 10 edges
The edge closest to the connection side is
edge 1.
The edge closest to the head side is edge 10.
The edges in between are assigned to num‐
bers 2...9 depending on their position.
Edges that are closer to 1 become 2 … 5,
edges closer to 10 become 9 ... 6.
There are more than 10 edges in the measure‐
ment f
ield
•
Total: > 10 edges
The first five edges on the connection side are
assigned to edges 1 ... 5, the last five edges on
the head side are assigned to edges 6 ... 10.
PLANNING 4
