Position 8 - 11 Meaning Type code specification -
Number whic
h can be ordered
9
Number of measurement modules
on the c
onnection side of the MLG-2
(left)
1: 1 measurement module
2: 2 measurement modules
…
9: 9 measurement modules
A: 10 measurement modules
…
G: 16 measurement modules
10
Number of empty modules 0: 0 empty modules
1: 1 em
pty module
2: 2 empty modules
...
9: 9 empty modules
A: 10 empty modules
...
J: 19 empty modules
11
Number of measurement modules
on t
he he
ad side of the MLG-2 (right)
0: 0 measurement modules
1: 1 measurement module
…
9: 9 measurement modules
A: 10 measurement modules
…
F: 15 measurement modules
Example calculation of measurement field width
•
N
umber of me
asurement modules on the connection side = 3
•
Number of empty modules = 1 piece
•
Number of measurement modules on the head side = 2
Measurement field width = (number of measurement modules on the connection side
+ number of empty modules + number of measurement modules on the head side)
x 150 mm – 5 mm
Measurement field width = (3 measurement modules + 1 empty module
+2 measurement modules) x 150 mm – 5 mm
Measurement field width = (3 + 1 + 2) x 150 mm – 5 mm
Measurement field width = 895 mm
3.2.2 Switching outputs of the MLG-2 WebChecker
Table 5: MLG-2 outputs
Position 12 Inputs and outputs, data interface Connection type
E
•
E
t
herCAT
®
+ 1 switching output M12, 4-pin
H
•
Ethernet/IP
TM
+ 1 switching output M12, 4-pin
N
•
PROFINET + 1 switching output M12, 4-pin
3.2.3 Optical properties
Table 6: Sensing range and minimum detectable object length
Position
14 and 15
Operating range Minimum detectable object length
00 Special Special
05 2.5 m 4 mm
PRODUCT DESCRIPTION 3
8025190/2020-01-13 | SICK O P E R A T I N G I N S T R U C T I O N S | MLG-2 WebChecker
