SICK MLG-2 WebChecker User Manual

Table 74: Part numbers for connecting cable with female connector
Type Head A connec‐
t
ion t
ype
Head B connec‐
tion type
Connecting cable Part no.
DOL-1205-G05MAC Female connec‐
tor
, M12,
5-pin, straight,
shielded
Cable, loose
c
able ends
5 m, 5-wire 6036384
DOL-1205-G02M Female connec‐
tor
, M12,
5-pin, straight,
unshielded
Cable, loose
c
able ends
2 m, 5-wire 6008899
DOL-1205-G05M 5 m, 5-wire 6009868
DOL-1205-G10M 10 m, 5-wire 6010544
DOL-1205-G15M 15 m, 5-wire 6029215
Table 75: Female connector part numbers
Type Head A connection type Head B connection type Part no.
DOS-1205-G Female connector, M12, 5-
pin,
st
raight, unshielded
Screw terminals 6009719
Table 76: PROFINET connecting cable part numbers
Type Head A connec‐
tion t
ype
Head B connec‐
tion type
Connecting cable Part no.
SSL-2J04-G03ME Male connector,
M12,
4-pin, D-coded,
shielded
Male connector,
R
J-45,
8-pin, straight
3 m, 4-wire,
AWG22
6029630
SSL-2J04-G05ME 5 m, 4-wire,
AWG22
6035389
SSL-2J04-G25ME 25 m, 4-wire,
AW
G22
6033555
Table 77: Ethernet connecting cable part numbers (configuration)
Type Head A connec‐
tion t
ype
Head B connec‐
tion type
Connecting cable Part no.
SSL-1204-G02ME Male connector,
M12,
4-pin, D-coded,
shielded
Male connector,
M12,
4-pin, D
-coded
2 m, 4-wire 6034420
SSL-1204-G05ME 5 m, 4-wire 6034422
Connection cable
(male connect
or-
male connector)
Male connector,
M12,
4-pin, straight,
D-coded,
shielded
Male connector,
R
J-45,
8-pin, straight
5 m, 4-wire,
AWG26
6034415
SSL-2J04-G02ME Male connector,
M12,
4-pin, st
raight,
D-coded,
shielded
Male connector,
R
J-45,
8-pin, straight
2 m, 4-wire,
AWG26
6034414
Table 78: Part number for MLG-2 connection cable to fieldbus module
Type Head A connec‐
tion t
ype
Head B connec‐
tion type
Connecting cable Part no.
DSL-1212-G2M7AC Female connec‐
tor
, M12, 12-pin,
straight
Male connector,
M12, 12-pin,
straight
2.7 m, 12-wire,
shielded,
shielded, PUR,
halogen-free
6056903
16 ACCESSORIES
124
O P E R A T I N G I N S T R U C T I O N S | MLG-2 WebChecker 8025190/2020-01-13 | SICK
Subject to change without notice
