Data Mapping module Description
Data Mapping Egy
Maps kWh, kVAh, and kVARh delivered, and received
data, including conditional, quadrant, and incremental
energies.
Data Mapping EN
Maps present interval EN 50160 power quality
compliance data.
Data Mapping EN Prev
Maps previous interval EN 50160 power quality
compliance data.
Data Mapping IEEE519 Maps IEEE 519 harmonics compliance data.
Data Mapping I/O
Maps input metering data, alarms, resets, and reset
counts.
Data Mapping Meas
Maps voltage, current, power, power factor, and
frequency data for one second and half-cycle
measurements.
The Cfg Modbus Map Enable setup register may exist in
this module.
Data Mapping PQ
Maps power quality data such as Crest Factor, K Factor,
and total harmonic distortion, including IEC 61000-4-30
power quality compliance data.
Data Mapping Stats
Maps statistical low, mean, and high data values, such
as I a mean (phase A current average value).
Data Mapping TOU
Maps time-of-use (TOU) data, such as seasons, rates,
and per-season demand, such as kW sd rec A (sliding
demand kilowatts received in season A).
You can add extra Modbus information or duplicate information that is already in the fixed map to
different Modbus registers using Modbus Slave modules.
For more information on Data Mapping modules and Modbus Slave modules, see ION Reference,
available on www.usa.siemens.com/pds.
Configuring custom Modbus data using ION Setup
You can add custom data to your meter's default Modbus map, completely customize your
meter's Modbus map, or revert your meter's Modbus map back to its default configuration using
ION Setup.
Download your meter’s Modbus map information from www.usa.siemens.com/pds.
To configure custom data using ION Setup:
1. Start ION Setup.
2. Open the Setup Assistant for your meter.
