9810 specifications 9810 series - User manual
295 7EN05-0390-08
Environmental characteristics
Operating temperature
–25 ºC to Max temp (–13 ºF to Max temp)
NOTE: Maximum operating temperature could change
based on the quantity and type of attached option modules.
See Maximum operating temperature with option modules
below.
Storage temperature –40 °C to 85 °C (–40 °F to 185 °F)
Humidity rating
5%–95% RH non-condensing
Maximum dewpoint: 37 °C (99 °F)
Pollution degree 2
Altitude < 3000 m (9843 ft) above sea level
Location/mounting
Not suitable for wet locations
For indoor use only
Must be permanently connected and fixed
Maximum operating
temperature
948M2DO6DI
Digital (2 out, 6 in)
948M2AO4AI
Analog (2 out, 4 in)
70 ºC (158 ºF) 0–4 0,1
70 ºC (158 ºF) 0 2
60 ºC (140 ºF) 1, 2 2–4
Maximum operating temperature with option modules
LEDs
Type Visible orange, infrared
Wavelength 600–609 nm (orange), 825–925 nm (infrared)
Maximum pulse rate 10 Hz (100 ms)
Energy pulsing LEDs (visible and infrared)
Type Bi-color, red/green
Status LEDs (visible)
