Logging 9810 series - User manual
223 7EN05-0390-08
Transient Log
The Transient Log (Data Rec 15) provides details of power quality events. Factory settings for this
data recorder:
Factory settings for this data recorder:
•
Log depth = 100 records
•
Interval = Triggered on demand
By default, it logs the following values:
TR1 TranV1Dur TR1 TranV3Dur PM1 PT Prim
TR1 TranV1Max TR1 TranV3Max PM1 PT Sec
TR1 TranV2Dur TR1 TranNominal PM1 CT Prim
TR1 TranV2Max TR1 Threshold PM1 CT Sec
EN 50160 compliance logs
The EN 50160 compliance logs are used to record EN 50160 compliance counters:
Data recorder Description
EN50160 Flicker (Data Rec 18) Flicker
EN50160 Frq/Mg (Data Rec 17) Power frequency and supply magnitude
EN50160 Hrm Vlt (Data Rec 29) Voltage harmonics
EN50160 Ihm Vlt (Data Rec 30) Voltage interharmonics
EN50160 Intrp (Data Rec 24) Short/long interruptions
EN50160 MSignal (Data Rec 31) Evaluation of mains voltage signals
EN50160 Prm-f/V (Data Rec 32) Frequency and supply voltage statistics
EN50160 Prm-Flk (Data Rec 33) Flicker statistics (Pst and Plt)
EN50160 PrmHrm1 (Data Rec 12) Harmonics statistics
EN50160 PrmHrm2 (Data Rec 11) Harmonics statistics overflow
EN50160 Swell (Data Rec 25) Voltage swells
EN50160 Vlt Dp1 (Data Rec 19) Supply voltage dips
EN50160 Vlt Dp2 (Data Rec 20) Supply voltage dips
EN50160 Vunbal (Data Rec 28) Voltage unbalance
The meter logs EN 50160 counter data for present and previous observation periods as well as
EN 50160 events.
For more information about EN 50160, see the Power Quality: ION Meters and EN50160:2010
technical note, available on www.usa.siemens.com/pds.
