Maintenance 9810 series - User manual
273 7EN05-0390-08
The meter is usually reading data from a test power supply while function verification is
performed.
The values shown in the test mode display screens represent different accumulators than those
shown in norm or alt mode (although they perform some of the same basic measurements). The
test mode display values are for accuracy checking purposes; they only accumulate while the
meter is in test mode.
You can create custom test mode screens and modify the existing test mode screens.
NOTE: You cannot place revenue-locked meters into test mode.
Several things to note about test mode:
•
All of the billing quantities that are recorded when the meter is in Normal mode stop
accumulating when the meter is switched to test mode – the data is sent to special test mode
registers instead.
•
The values accumulated in these test registers are displayed on the test mode displays and in
ION Setup.
•
The regular normal mode billing registers are unaffected while the meter is in test mode;
accumulation of this data continues as soon as you exit test mode.
•
All test registers are reset to zero when you exit test mode.
Test mode default screens
Your meter has default test mode display screens.
NOTE: You can modify the test mode display screens or add custom screens using ION Setup.
Screen Description
Demand test
This screen shows test mode kW delivered and received values.
Both quantities are produced from a sliding window (rolling block)
demand calculation.
Reactive energy test
This screen shows test mode kVARh delivered and received
values.
Active energy test This screen shows test mode kWh delivered and received values.
Putting your meter in test mode using ION Setup
NOTE: You cannot place a revenue-locked meter into test mode.
To put your meter into test mode using ION Setup:
1. Start ION Setup.
2. Open the Setup Assistant for your meter.
3. Navigate to Verification and select the Verification tab.
