3. Click Displays > Front Panel.
4. Select Displays and click Edit.
ION Setup loads your meter’s display information into the Display Editor screen.
5. Select the display mode of the custom screens from the drop-down list box, and rename,
delete, or change the order of custom displays.
a. Click New to add a new display screen in the selected display mode.
b. Click Edit to open the Display setup screen, where you can configure new or existing
custom displays.
6. Configure your screen.
Screen Type: Specify the number of parameters displayed on the screen.
Screen Title: Enter the title to be shown at the top of your custom display.
7. Click Edit to select the displayed parameters.
The number of parameters displayed is determined in the Screen Type selection described
above.
8. Select your digit display properties.
Resolution: Specifies the number of decimal places displayed.
Last Digit: Specifies if the last digit is rounded or truncated.
9. Click Send to save the changes in the meter.
Display units scaling
You can customize the units for metered values shown on the display and webpages.
You can configure the units for voltage, current, power and energy values shown on the display
and webpages from their default units, and you can set the resolution for the display. To identify
which values will have the modified units, refer to the display and web units information in your
meter’s Modbus map, available from www.usa.siemens.com/pds.
Configuring display units scaling using ION Setup
You can customize the units for metered values shown on the display and webpages using ION
Setup.
Configuring display units scaling is an advanced procedure that requires in-depth knowledge of
your meter, its underlying architecture, and the system in which it is installed.
To identify which values will have the modified units, refer to the display and web units information
in your meter’s Modbus map, available from www.usa.siemens.com/pds.
NOTE: Custom units and resolution settings are automatically adjusted for current and voltage
values to help prevent the display from showing incorrect zero values.
1. Start ION Setup.
2. Connect to your meter in advanced mode.
3. Navigate to the Display Options Modules folder and double-click on the module in the right-
hand pane.
9810 series - User manual Display
7EN05-0390-08 174
