Logging 9810 series - User manual
229 7EN05-0390-08
Waveform recorder Description
Vfm Rc V3-Trnst (Wform Rec 11)
V3 voltage waveforms recorded during a defined
transient event.
Vfm Rc I1-Trnst (Wform Rec 13)
I1 current waveforms recorded during a defined
transient event.
Vfm Rc I2-Trnst (Wform Rec 14)
I2 current waveforms recorded during a defined
transient event.
Vfm Rc I3-Trnst (Wform Rec 15)
I3 current waveforms recorded during a defined
transient event.
COMTRADE modules
The factory-default COMTRADE modules are preconfigured with their inputs linked to the Trigger
outputs of the waveform recorders for sag/swell and transient monitoring.
COMTRADE 1 inputs (sag/swell) Linked Waveform Recorder (Trigger output)
Waveform Trigger 1 Wfm Rc V1-Sg/Sw (Wform Rec 1)
Waveform Trigger 2 Wfm Rc V2-Sg/Sw (Wform Rec 2)
Waveform Trigger 3 Wfm Rc V3-Sg/Sw (Wform Rec 3)
Waveform Trigger 4 Wfm Rc I1-Sg/Sw (Wform Rec 5)
Waveform Trigger 5 Wfm Rc I2-Sg/Sw (Wform Rec 6)
Waveform Trigger 6 Wfm Rc I3-Sg/Sw (Wform Rec 7)
COMTRADE 2 inputs (transient) Linked Waveform Recorder (Trigger output)
Waveform Trigger 1 Vfm Rc V1-Trnst (Wform Rec 9)
Waveform Trigger 2 Vfm Rc V2-Trnst (Wform Rec 10)
Waveform Trigger 3 Vfm Rc V3-Trnst (Wform Rec 11)
Waveform Trigger 4 Vfm Rc I1-Trnst (Wform Rec 13)
Waveform Trigger 5 Vfm Rc I2-Trnst (Wform Rec 14)
Waveform Trigger 6 Vfm Rc I3-Trnst (Wform Rec 15)
Event log
Your meter records events produced by the meter’s ION modules or external meter events.
Meter events, such as meter configuration or changes to I/O state, have priority values associated
with them, so you can control what events are logged. Each event has a priority based on its type
and severity, and for most events you can configure the priority. The event log records the date
and time of the event, along with relevant details about the event.
Your meter’s event log can be viewed through ION Setup and the display.
For more information on how to view the event log, see "Viewing and downloading an event log"
on page 51.
