Communications 9810 series - User manual
117 7EN05-0390-08
Folder Description
COMTRADE_1 to
COMTRADE_3
View COMTRADE files from these folders. Users have read
permission of files.
documents Add any file type to this folder. Users have full control of files.
IEC61850
Add an IEC 61850 configuration (CID) file to this folder to activate
IEC 61850 functionality. Users have full control of files in the root
and read permission of files in the log folder.
optionModuleUpg and
rmdUpg
Upload firmware upgrade files for your meter’s display or option
modules to these folders. Users have full control of files.
web
Add custom webpages to the meter by transferring them into web
subfolders. This folder is where default meter webpages are
stored. Users have full control of files.
SFTP file name restrictions
The names of files sent to the meter using SFTP:
•
Cannot include spaces
•
Cannot include \ / , * ? < >
•
Cannot exceed 50 characters(including the file extension)
Simple Network Management Protocol (SNMP)
Your meter supports Simple Network Management Protocol (SNMP) after you have enabled
SNMP on your meter. You need to upload the meter’s Management Information Base (MIB) file
(available from www.usa.siemens.com/pds) into the Network Management System (NMS)
managing your meter.
SNMP is part of the Transmission Control Protocol/Internet Protocol (TCP/IP) protocol suite.
SNMP is an application layer protocol that enables the exchange of network management
information between devices, allowing you to manage network performance and to identify and
solve problems on networks with devices of various types.
SNMP configuration assumes that you have an advanced understanding of SNMP and the
communications network and power system that your meter is connected to.
Key terms
Term Definition
Agent
Software resident on the managed device which interfaces
between the device and the NMS.
Managed device Your meter in the SNMP network.
Community name/string
A text string that helps authenticate requests between the
managed device and the NMS.
Managed object Any parameter referenced in the MIB file.
