Parameter Value/Range Description
Input Mode
Pulse, KYZ, A/C,
IRIG-B*
Specifies how the meter processes the signal:
•
Pulse: the meter counts an entire pulse (from off-
on to on-off) as one input.
•
KYZ: the meter counts a transition (from off-on or
from on-off) as one input.
•
A/C: the meter detects analog signals where the
ON condition is based on the presence of an AC
signal.
•
IRIG-B*: the meter detects an IRIG-B time
synchronization signal.
EvLog Mode Log Off/Log On Specifies if events generate log entries.
Event Priority 0–255 Specifies the priority of an event.
Polarity
Inverting/Non-
Inverting
Specifies if the signal from the digital port is inverted
or not inverted.
Debounce 0.000–1.000
Specifies how long (in seconds) the signal must
remain in a state to be considered a valid state
change.
Port
Defined by your
meter’s hardware
Your meter’s physical digital input port.
Enable Enabled/Disabled Specifies whether the module is enabled or disabled.
Alarm Trigger
Mode
Alarm on ON/Alarm
on OFF
Specifies the behavior of the digital input alarm.
* IRIG-B time synchronization is not supported on the option module digital inputs.
WAGES monitoring
WAGES monitoring lets you record and analyze all energy sources and utilities usage.
Your system may use several different types of energy. For example, you may consume steam or
compressed air for industrial processes, electricity for lights and computers, water for cooling and
natural gas for heating. WAGES monitoring collects the usage information from all these different
energy sources to enable a more complete energy analysis.
WAGES information can help you:
•
Identify losses or inefficiencies.
•
Modify demand to reduce costs.
•
Optimize energy source usage.
WAGES monitoring example
The following example shows WAGES monitoring for a water flow meter.
9810 series - User manual Inputs/Outputs
7EN05-0390-08 138
