Logging 9810 series - User manual
219 7EN05-0390-08
The meter can support up to 100 data recorders, which can each record up to 16 different
parameters.
Revenue Log
The Revenue Log (Data Rec 1) is configured for use with UTS MV-90 billing software.
Factory settings for this data recorder:
•
Log depth = 3360 records (35 days)
•
Interval = 900 seconds (15 minutes)
By default, it logs the following values:
Parameter Description
kWh del int Interval kWh delivered
kWh rec int Interval kWh received
kVARh del int Interval kVARh delivered
kVARh rec int Interval kVARh received
Historic data logs
Three historic data logs are used to record standard power system quantities, such as phase
current, phase voltage, and power factor. These logs are labeled Hist Mean Log, Hist High Log,
and Hist Low Log.
Factory settings for these data recorders:
•
Log depth = 3360 records (35 days)
•
Interval = 900 seconds (15 minutes)
By default, they log the following values:
Hist Mean Log (Data Rec 2)
Vll ab mean V unbal mean I avg mean kVA tot mean
Vll bc mean Ia mean I 4 mean PF lag mean
Vll ca mean Ib mean kW tot mean PF lead mean
Vll avg mean Ic mean kVAR tot mean Freq mean
Hist High Log (Data Rec 3)
Vll ab high V unbal high I avg high kVA tot high
Vll bc high Ia high I 4 high PF lag high
Vll ca high Ib high kW tot high PF lead high
Vll avg high Ic high kVAR tot high Freq high
