3. Click Alarming > Standard.
NOTE: You can manually configure setpoint values by selecting the setpoint and clicking
Edit.
4. Select a setpoint and click Learn.
The Global Setpoint Learning screen is displayed.
5. Select the setpoint tabs to view existing configured or learned setpoint information.
6. Click Setup.
The Alarm Learning Setup screen is displayed.
Parameter Value/Range Description
Install mode
Automatic,
Manual
Automatic: The learned values are automatically
applied.
Manual: The learned values are stored for you to
review and enter.
Duration 1–365 Days for maximum learning duration.
Setpoint learning parameters
7. Configure the learning parameters for each setpoint and click Save.
8. Click Start All to begin setpoint learning for all setpoints. Click Yes to confirm or No to
cancel.
Learning status and time remaining are indicated in the Learning Status box.
Click Abort to stop learning for a specific setpoint. To stop all setpoint learning, repeat
for each setpoint tab.
9. Apply the learned setpoint values:
Automatic: The setpoint values are automatically applied unless the learning process
has issues or the learned values are invalid.
Manual: Navigate to Alarming > Setpoints, and then click Learn. On each setpoint
tab, click Install to apply the learned values to that setpoint.
NOTE: If you click Install while learning is in progress (in either manual or automatic
installation mode), it stops the learning process and prompts you for confirmation that you
want to stop learning and install the learned values. Once you confirm, the learned values
are automatically installed or prepared for manual installation.
Implementing sag and swell limit learning using ION Setup
You can use ION Setup to implement voltage sag/swell learning, which analyzes your power
system and recommends settings.
NOTE: Your meter’s power system must be stable to learn valid sag/swell limits.
NOTE: Learning is not supported for Current Swell and Current Sag.
9810 series - User manual Alarms and alerts
7EN05-0390-08 192
