NOTE: To perform specialized configuration go into the advanced mode of ION Setup and
modify, disable or add a new Calibration Pulser module. These are advanced procedures that
should only be performed if you have advanced knowledge of ION and the power system your
meter is connected to.
For more information on the Calibration Pulser module, see ION Reference, available on
www.usa.siemens.com/pds.
Configuring digital output energy pulsing using ION Setup
You can configure your meter’s onboard digital outputs for energy pulsing using ION Setup.
When configuring your meter, the configuration interface may show all the possible ports,
regardless of what is physically available on your meter.
Ensure that the digital output port is available for energy pulsing and not associated with another
function.
NOTE: For applications where accuracy is important, use the digital output located on the meter
base.
1. Start ION Setup.
2. Open the Setup Assistant for your device.
3. Select Energy pulsing.
4. Select an energy pulsing source tab (such as Wh Del) to configure energy pulsing using
your meter’s digital output.
Parameter Description
Kt
The amount of energy source required to trigger the digital output. For
example, in the Wh Del tab, the Kt value would be amount of real energy
delivered (Wh Del) per pulse.
Pulse Width The minimum time in seconds between pulse transitions.
OutputMode
Select the desired output mode:
•
Pulse: the digital output sends a complete pulse when triggered.
•
KYZ: the digital output makes a transition (off-to-on, or on-to-off) when
triggered.
Port
Select an output port from the list. Only available output ports are shown
(ports that are not associated with another function).
(energy source)
ovrld
Pulsing normally indicates that the output port should be operating normally.
Pulsing suspended indicates that the output port is not able to pulse quickly
enough. Modify the Kt value to decrease the number of energy pulses.
Digital output energy pulsing parameters available through ION Setup
