Communications 9810 series - User manual
83 7EN05-0390-08
To configure Ethernet communications settings using the display:
1. Press Setup Menu > Communications Setup.
2. Scroll through the screens until you reach the setting you want to configure then press the
Edit button.
3. Select the IPv4 or IPv6 Assignment Mode, if required.
Option Description
Stored
The meter uses the IP addresses that you manually enter for
IPv4 (address, subnet mask and gateway) and IPv6 (Global
address, gateway address).
DHCP/DHCPv6
The meter acquires its IP addresses from your network’s
DHCP server.
You can have different assignment modes for IPv4 and for IPv6.
If you set the IPv4 Assignment Mode to Stored, continue with the remaining steps to
configure stored IPv4 addresses. If you are using addresses acquired from a DHCP server,
press the down arrow to view the assigned addresses.
4. Go to the Stored IPv4 Address Setup screen and press Edit.
5. Configure your meter’s stored IPv4 Addresses, as required.
Parameter Values Description
IP Address
Contact your local
network administrator for
parameter values.
Sets the IP address for the meter
Your meter’s default IP address is
169.254.0.10
Subnet Mask
Contact your local
network administrator for
parameter values.
Used if subnetting applies to your network
Your meter’s default subnet address is
255.255.0.0
Gateway
Contact your local
network administrator for
parameter values.
Used in networks with multiple segments
Your meter’s default gateway address is
0.0.0.0
MAC Address Read-only
Your meter’s media access control (MAC)
address
Stored IPv4 address settings available using the display
DHCP
The meter can function as a DHCP (Dynamic Host Configuration Protocol) client, allowing a
DHCP server to assign IP addresses to the meter.
